ASSEMBLY AND QUALITY CONTROL MACHINE FOR WITOL
The operator manually places 4 plastic washers for the assembly of 4 Witol components into the nests of the work station. After pressing the START CYCLE button, an automatic assembly and final product inspection cycle is initiated.
Station 1: Manual placement of 4 plastic washers.
Station 2: Automatic placement of 2 screws.
Station 3: Automatic placement of 2 screws.
Station 4: Automatic pressing of the washers onto the screws.
Station 5: Automatic placement of 2 nuts.
Station 6: Automatic placement of 2 nuts.
Station 7: Automatic screwing of 2 sets of screws and nuts.
Station 8: Automatic screwing of 2 sets of screws and nuts.
Station 9: Inspection and measurement.
Station 10: Sorting into good and defective units.
